An irrigation trenching assembly sets lateral and main lines over a four-inch sand bedding resting on undisturbed subgrade. Compacted backfill fills the trench up to the finish grade, maintaining a minimum four-inch separation between parallel pipes. Tracer wire is taped to the pipe line every fifteen feet on center. Pipe stacking is explicitly prohibited.
12" 18" VARIES MAINTAIN 4" BETWEEN PIPES LEGEND LATERAL LINE MAIN LINE FINISH GRADE COMPACTED BACKFILL TAPE WIRE TO LINE 15'-0" O.C. 4" SAND BEDDING UNDISTURBED SUBGRADE 1 DO NOT STACK PIPE ON TOP OF OTHER PIPE. 2 3 4 5 NOTES: 6 7 1 2 4 5 6 7 3
