A reinforced concrete wall corner features a thickness t. Reinforcement consists of #4 bars spaced at 12 inches on center on each face in both vertical and horizontal directions. Two #5 bars are provided at the corner termination. A 2-foot minimum development length is required for the horizontal reinforcement at the corner junction.
Text on the drawing
t t" 2'-0" MIN TYP PLAN VIEW (2) #5 SEE PLAN #4 @ 12"OC EA FACE (VERT & HORIZ) D
