A panel-mounted brass fixture is installed on a fume hood side wall, featuring a pre-piped concealed plumbing assembly connected to a forged brass valve body with a fine control needle valve. The mounting arrangement utilizes a three-eighths-inch IPS mounting shank secured with a locknut and washer, terminating in an angle serrated hose end with an epoxy color-coated panel-mounted brass flange. Operation is controlled via an angled four-arm handle positioned below the mounting surface.
3/8" IPS MOUNTING SHANK w/ LOCKNUT AND WASHER FORGED BRASS VALVE BODY w/ FINE CONTROL NEEDLE VALVE FORGED BRASS FOUR ARM HANDLE FUME HOOD SIDE WALL CONCEALED PLUMBING PRE-PIPED @ FACTORY FOUR-ARM HANDLE EPOXY COLOR COATED PANEL MOUNTED BRASS FLANGE w/ ANGLE SERRATED HOSE END
