A circuit breaker or fused disconnect feeds three-phase power lines L1, L2, and L3 into the heat recovery chiller modular control panel along with an electrical ground connection. Building automation system low voltage wiring utilizing 20-2 shielded cable connects to the control panel terminals for communication and monitoring.
E BAS CIRCUIT BREAKER OR FUSED DISCONNECT AS REQUIRED GROUND L1 L2 L3 HEAT RECOVERY CHILLER MODULAR CONTROL PANEL 20-2 SHIELDED LOW VOLTAGE WIRING
