The assembly features a cumaru hardwood seat mounted to a galvanized steel base structure with attachment holes sized per manufacturer's drawings. The bench rests upon a cast-in-place concrete pad sized per structural drawings over an aggregate base layer. Geofoam fill is positioned below the aggregate base for subgrade support.
2' - 11 6/16". 1' - 6 1/2" 2 10/16". CUMARU HARDWOOD GALVANIZED STEEL ATTACHMENT HOLES SEE MANUFACTURER'S DRAWINGS CAST IN PLACE CONCRETE SEE STRUCTURAL DRAWINGS AGGREGATE BASE SEE STRUCTURAL DRAWINGS GEOFOAM 1' - 9 5/16" CENTERLINE
