L-9NX84 — Elevator Rail Support

Landscape · L-9NX84

Elevator Rail Support

Units: imperial
Sheet: LO-S1.2.5
Discipline: Landscape

Materials

Steel Timber / Wood

Elements

Anchors / Embeds Beams Columns Connections / Plates

Connections

Base Plate / Anchorage Bolted Connection Expansion / Slip Connection HSS Connection Timber / Mass-Timber Connection Welded Connection

Text on the drawing

CONN AT UNDERSIDE OF BEAM 3" 4" TYP 1/2" 3/16 3/16 CAP PL 1/4 COL PL 3/8 EA SIDE HSS COL PER PLAN 3/4"ø A325 BOLT IN LONG VERT SLOT FINGER TIGHT w/ DBL NUT DIST TYP 1" EDGE C L 1/2" CLT PANEL PER PLAN PL 1/2x10x10 W/ (8) MTC SOLUTIONS KOMBI 5/16 X 3 1/8" SCREWS
