An irrigation controller enclosure sits atop a steel base with mounting studs, secured to an eight-inch concrete slab finished at grade with a two percent minimum slope to drainage. A 120-volt A.C. electrical service is routed to the controller via rigid steel conduit connected to a ground-fault circuit interrupter switch. Low-voltage control wires enter through a schedule 40 grey PVC electrical conduit with a sweep elbow and secure to a terminal strip inside the enclosure. A grounding rod penetrates the concrete pad through a protective PVC sleeve and connects to a grounding lug.
SECTION LOW VOLTAGE CONTROL WIRES (AWF) SECURE TO TERMINAL STRIP 2'-0" MIN ALL SIDES 1" 2" 8" 2% MIN 2% MIN FINISH GRADE CONCRETE SLAB SLOPE TO DRAIN STEEL BASE WITH MOUNTING STUDS INCLUDED SCHEDULE 40 GREY PVC ELECTRICAL CONDUIT WITH SWEEP ELL FOR LOW VOLTAGE WIRE CONTROLLER ENCLOSURE 120 VOLT A.C. ELECTRICAL SERVICE TO CONTROLLER. PROVIDE RIGID STEEL CONDUIT FROM POWER TO GFCI SWITCH AND COMPLETE ELECTRICAL SERVICE TO CONTROLLER. INSTALL PVC SLEEVE AROUND GROUND ROD THROUGH CONCRETE PAD 1'-2" 35'' OVERALL WITH TOP CLOSED GROUNDING LUG
