L-9JB2H — Mechanical Screen Offset Connection

Landscape · L-9JB2H

Mechanical Screen Offset Connection

Scale: 3/8" = 1'-0"
Units: imperial
Sheet: LO-S6.0.2
Discipline: Landscape

Materials

Elements

Beams Columns Connections / Plates Facades / Cladding

Connections

Beam-to-Column HSS Connection Welded Connection

Text on the drawing

6 HSS3x3x3/16 PL 3/8x4x4 PANEL SCREEN, S.A.D. WIND GIRT HSS POST 3/16 TYP WIND GIRT TO ANGLE, SEE X/XX WIND GIRT 16" MAX 2"MIN 2"MIN 3/8" = 1'-0" 2
