A precast concrete table stands three feet high with a one-inch corner radius and angled sides measuring 75.5 degrees and 75.6 degrees. The table pedestal extends down through concrete unit paving and rigid insulation to bear on a concrete curb. Below the curb, a waterproofing system separates the assembly from the structural slab. Dimensions indicate a pedestal width of one foot eight and five-eighths inches on the left and a variable width on the right.
3' - 0" 1" RADIUS 1" RADIUS VARIES PRECAST CONCRETE TABLE PEDESTAL CONCRETE CURB STRUCTURAL SLAB SEE ARCHITECTURAL DRAWINGS WATERPROOFING SYSTEM SEE ARCHITECTURAL DRAWINGS CONCRETE UNIT PAVING RIGID INSULATION SEE ARCHITECTURAL DRAWINGS 3' - 0" 1' - 8 5/8" 75.5° 75.6° PRECAST CONCRETE TABLE PEDESTAL CONCRETE UNIT PAVING RIGID INSULATION SEE ARCHITECTURAL DRAWINGS CONCRETE CURB WATERPROOFING SYSTEM SEE ARCHITECTURAL DRAWINGS STRUCTURAL SLAB SEE ARCHITECTURAL DRAWINGS
