The assembly features a rotomolded plastic bin that tilts in either direction for emptying, secured to a metal frame with a lock, latch for bin release, and a metal diverter with an 11-1/2-inch by 16-1/2-inch opening bolted to the frame. The unit is surface mounted to a concrete substrate using two 21/32-inch diameter anchor holes with non-corrosive 3/8-inch anchoring hardware supplied by others. A set screw is provided for the cover plate at the base. The total height of the unit is 3'-2" with specific vertical clearance and opening dimensions.
2'-1" 5" 3'-2" 5" 2" 9" NOTE UNIT MUST BE SURFACE MOUNTED. METAL DIVERTER WITH 11-1/2" x 16-1/2" [292 x 419] OPENING BOLTED TO FRAME ROTOMOLD PLASTIC BIN TILTS EITHER DIRECTION FOR EMPTYING LOCK LATCH FOR BIN RELEASE SET SCREW FOR COVER PLATE (2) Ø 21/32 [17] HOLES FOR ANCHORING. NON-CORROSIVE Ø 3/8 [10] ANCHORING HARDWARE SUPPLIED BY OTHERS. FRONT SIDE
