L-8NMYX — Typ Wall Intersections At Non-Rated Wall

Landscape · L-8NMYX

Typ Wall Intersections At Non-Rated Wall

Units: imperial
Sheet: LO-S1.4.2
Discipline: Landscape

Materials

Cold-formed Steel Timber / Wood

Elements

Partitions Walls

Text on the drawing

LO S1.4.5 DBL STUD @ CORNERS TYP CORNER #10 SMS @ 16" OC TYP STUD WALL 4" OR 6" #10 SMS @ 16" OC TYP PERPENDICULAR INTERSECTION #10 SMS @ 16" OC TYP PER PLAN STUDS

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
