A concrete paving assembly is supported by a compacted aggregate base and compacted subgrade. The concrete slab features a one-half-inch tooled radius at the exposed edges adjacent to finish grade. A control joint with a type that varies is provided as indicated on the plan. Thicknesses for the concrete, aggregate base, and subgrade vary and are coordinated with civil engineering drawings.
NOTE: 1/2" TOOLED RADIUS AT EDGES FINISH GRADE 4" VARIES, SEE CIVIL VARIES, SEE CIVIL CONTROL JOINT- TYPE VARIES (SEE PLAN) CONCRETE PAVING COMPACTED AGGREGATE BASE COMPACTED SUBGRADE
