Irrigation drip tubing is laid out with enough slack to enable manipulating emitters in the field. One emitter is placed on the rootball for one-gallon containers or smaller. Two emitters are placed on the rootball for five-gallon containers. Three emitters are placed on the rootball for fifteen-gallon containers.
NOTE: 1. LAY OUT IRRIGATION DRIPLINE WITH ENOUGH SLACK TO ENABLE MANIPULATING EMITTERS IN THE FIELD AS SHOWN IN THIS DIAGRAM. 1 GALLON CONTAINER (OR SMALLER), PLACE 1 EMITTER ON ROOTBALL 5 GALLON CONTAINER, PLACE 2 EMITTERS ON ROOTBALL 15 GALLON CONTAINER, PLACE 3 EMITTERS ON ROOTBALL PLAN
