Concrete unit paving measuring twelve by twelve by two inches is laid over a one-inch mortar setting bed. The mortar rests on a four-inch cast-in-place concrete base. A five-eighths-inch crushed rock base sits directly over the compacted subgrade. The assembly abuts cast-in-place concrete paving at the edge.
ADJACENT CIP CONCRETE PAVING, REF 1/320 CONCRETE UNIT PAVING 12"x12"x2" CONCRETE BASE 2" 1" 4" 5/8 CRUSHED ROCKBASE MORTAR SETTING BED COMPACTED SUBGRADE
