A concrete slab thickened edge rests on a compacted subgrade with a minimum nine-inch vertical dimension and an eight-inch horizontal footing extension. The top corner features a one-quarter-inch rounded tooled edge finished without shiners or tool marks, adjacent to the exterior finish grade.
FINISH GRADE MIN. 9" 8" 5 1/4" R. TOOLED EDGE, TYP. NO SHINERS OR TOOL MARKS C. THICKENED EDGE
