L-5MDA6 — Detail Notes:

Landscape · L-5MDA6

Detail Notes:

Units: imperial
Sheet: LO-T2.0.7
Discipline: Landscape

Materials

EIFS / Plaster / Stucco Metal (misc.)Steel

Elements

Connections / Plates

Text on the drawing

CAT 6A UTP SINGLE GANG FACEPLATE, KEYSTONE COMP. DOUBLE GANG PLASTER REDUCTION RING INSULATED THROAT COMPRESSION TYPE STEEL CONNECTOR 1"C TO CABLE TRAY (TYP.) 4" SQUARE x 2-1/8" DEEP OUTLET BOX. 8P8C JACK KEYSTONE MODULE
