L-5DERY — Groundcover Spacing

Landscape · L-5DERY

Groundcover Spacing

Elements

Walls Site / Paving

About this detail

Plant specimens are arranged in an equilateral triangular grid pattern with a sixty-degree angle. Spacing on center is defined as 'S', with row spacing calculated as 0.86 times 'S'. The offset from the edge of the plant bed, curb, walk, fence, or wall is maintained at one-half 'S' unless otherwise specified.

'S' 'S' 1/2 'S' UNLESS OTHERWISE SPECIFIED NOTE: 'S' = SPACING ON CENTER AS SHOWN ON PLANS EQUILATERAL TRIANGULAR SPACING 60° ROW SPACING = 0.86 X 'S' PLANT SPECIMEN EDGE OF PLANT BED, CURB, WALK, FENCE OR WALL \
