A custom concrete firepit by Concreteworks sits atop a concrete footing, supported by a structural concrete slab with integrated drainage layers. The fire feature incorporates a steel tray holding crushed lava rock over an HPC burner. Gas controls and an emergency shutoff are housed behind a moveable weathering steel Cor-ten plate. The assembly rests above brick paving set over specialized sub-base layers and a structural steel deck slab.
Crushed Lava Rock In Steel Tray Over HPC Burner Controls and Emergency Shutoff Behind Moveable Corten Plate 1" Customized Firepit, By Concreteworks Structural Slab, See Structural Drawings Concrete Footing, See Structural Drawings See Architectural Drawings 11" 1'-5" 8" 11" 8 L9.01 Brick Paving
