L-4SDYG — Curtain Wall Parapet

Landscape · L-4SDYG

Curtain Wall Parapet

Scale: 1" = 1'-0"
Units: imperial
Sheet: LO-S1.6.4
Discipline: Landscape

Materials

Glass / Glazing Steel Timber / Wood

Elements

Beams Connections / Plates Curtain Walls Parapets Roofs Walls

Connections

Timber / Mass-Timber Connection

Text on the drawing

9 CLT PANEL ROOF PER PLAN GLAZING S.A.D. CLOSURE WALL ATTACHMENT TO CURTAIN WALL PER CURTAIN WALL MANUFACTURER 3 5/8" CLOSURE WALL 1 3/4" 3/4" L6X6X1/4 CONT ANGLE ALIGNED WITH CLT EDGE
