Landscape · L-4DYV6

Quick Coupler Valve

Materials

Elements

About this detail

A quick coupler valve is installed per plan and set plumb within a Carson standard valve box featuring a locking lid, positioned flush with the finish grade. The assembly connects to a Schedule 40 PVC main line using Schedule 80 PVC nipples, street ells, 90-degree ells, and a Schedule 80 PVC threaded tee with a three-inch length nipple. Two stainless steel hose clamps secure the connection, providing a two-inch clearance below the lid. A thirty-six-inch length steel tee fence post provides vertical support, and the installation rests on a six-inch depth of drain rock.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
