Building automation system connections include a 0-10VDC or 4-20 mA speed signal originating from a differential pressure sensor alongside a variable frequency drive alarm status signal.
BAS BAS BAS 0-10VDC OR 4-20 mA SPEED SIGNAL FROM DIFFERENTIAL PRESSURE SENSOR VFD ALARM STATUS
