An irrigation main or lateral line and spare irrigation line sleeve with a minimum three-inch diameter are set within a trench beneath hardscape and aggregate base backfill. The trench requires a minimum twenty-one-inch width to allow for compaction to ninety-five percent with a six-inch minimum clearance. A control wire conduit with a minimum one-inch diameter runs alongside the sleeves. Epoxy-coated rebar stakes with blue caps are positioned flush to the top of the hardscape for sleeve location identification.
6" MINIMUM IRRIGATION LINE SLEEVE MIN 3" TRENCH WIDTH 21" MINIMUM TO ALLOW FOR COMPACTION TO 95% AGGREGATE BASE BACKFILL IRRIGATION MAIN/LATERAL LINE HARDSCAPE 21" MIN. CONTROL WIRE CONDUIT MIN 1" 1' - 0" 1' - 0" SLEEVE LOCATION IDENTIFICATION REBAR STAKES W/BLUE CAP FLUSH TO TOP OF HARDSCAPE SECTION VIEW SLEEVE EPOXY COATED REBAR SPARE IRRIGATION LINE SLEEVE MIN 3"
