This drawing sheet compiles several hardscape and site furnishing construction details. The boulder wall assembly features boulders placed with a one-in-twelve batter over filter fabric and a compacted aggregate base, requiring structural engineering for walls over four feet high. The stone slab bench detail shows a stone bench with a flat saw cut and honed finish secured to a concrete footing using one-half-inch diameter by four-inch stainless steel pins, set above compacted crushed stone and subgrade. Additional details illustrate site furnishings anchored into concrete footings beneath concrete paving or chat surfaces.
