This drawing provides elevation, section, and plan views of the Landscape Forms Parc Vue bench with overall dimensions indicating a three-foot total height and a two-foot-two-inch depth. The section view details the bench profile anchored at the finish grade per the manufacturer's recommendations. Notes specify the exact model name, manufacturer, and refer to project specifications for additional information.
2'-3" 1'-6" FINISH GRADE ANCHOR PER MANUFACTURERS RECOMMENDATION NOTES MODEL: PARC VUE MANUFACTURER: LANDSCAPE FORMS SEE SPECS FOR ADDITIONAL INFORMATION SECTION ELEVATION PLAN 2'-2" 3'-0"
