L-3VYQH — Backing Stud To Vert Stud Connection

Landscape · L-3VYQH

Backing Stud To Vert Stud Connection

Units: imperial
Sheet: LO-S1.4.4
Discipline: Landscape

Materials

Cold-formed Steel Metal (misc.)Timber / Wood

Elements

Bracing Connections / Plates Partitions Walls

Connections

Bracing Connection

Text on the drawing

BACKING STUD TO VERT STUD CONNECTION VERT METAL STUD PER PLAN WHERE KICKER DOES NOT OCCUR BACKING STUD CONT PER PLAN 1/2" 1/2" G
