A concrete curb supports the planter assembly, anchored to the substrate with stainless steel headed anchor bolts and a waterproofing system coordinated with architectural drawings. The planter contains a drain course, filter fabric, and planting soil topped with mulch, with a 1-foot 6-inch vertical soil depth. The perimeter features a one-half-inch thick powder-coated stainless steel plate with a gusset plate and an integrated one-inch LED linear light. Adjacent to the planter, concrete unit pavers are supported on pedestals over rigid insulation.
1/2" THK SS PLATE POWDER COATED GUSSET PLATE SS HEADED ANCHOR BOLT CONCRETE CURB WATERPROOFING SYSTEM SEE ARCHITECTURAL DRAWINGS 1" LED LINEAR LIGHT CONCRETE UNIT PAVING PEDESTAL RIGID INSULATION 9" DRAIN COURSE 1' - 6" MULCH PLANTING SOIL WEEPHOLE, SEE ARCHITECTURAL DRAWINGS 1" 3" VARIES 3" FILTER FABRIC
