L-35RVR — Seamless Flooring At Walk Off Mat

Landscape · L-35RVR

Seamless Flooring At Walk Off Mat

Units: imperial
Sheet: LO-A9.4.1
Discipline: Landscape

Materials

Elements

Entrances Floors / Slabs

Text on the drawing

3/4" ALUMINUM LEVEL 3/16" 3/16" RECESSED WALK OFF MAT SLIP RESISTANT, CHEMICAL RESISTANT SEAMLESS RESINOUS FLOORING PER FINISH SCHEDULE 12 SEAMLESS FLOORING AT WALK OFF MAT
