L-2F4B4 — Conn Detail

Landscape · L-2F4B4

Conn Detail

Units: imperial
Sheet: LO-S1.4.1
Discipline: Landscape

Materials

Cold-formed Steel Metal (misc.)Steel Timber / Wood

Elements

Connections / Plates Partitions Walls

Connections

Rebar Splice / Development

Text on the drawing

TOP TRACK 5 EQ SPACES (6) #10 SMS EA SIDE 12" 1" 1" TOP TRACK TOP TRACK SPLICE 54 MILS MIN STUD TO MATCH TRACK WIDTH (12" LONG)
