A sixteen by sixteen inch security junction box supplies low-voltage cabling through three-quarter inch conduit to door security devices. The card reader mounts forty-eight inches above the finished floor and eight inches from the door frame edge. Cabling includes eighteen gauge two-conductor request-to-exit wiring, sixteen gauge three-conductor lock power, and twenty-two gauge multi-conductor feeds for card readers and door contacts. Conduits route typical to the security junction box above the door opening.
A D C B EL 16"x16" SECURITY JUNCTION BOX (1) 18/2 REX (1) 16/3 LOCK POWER (1) 20/8 FOR READERS 8" 48" (1) 20/2 CR DC 6" 3/4" CONDUIT TYPICAL FOR DEVICES 22/6 22/2
