A pop-up rotor sprinkler head is set flush with the finish grade and connected to an optional schedule 80 PVC nipple. The assembly ties into a swing joint linked to a schedule 40 PVC tee or elbow. The fitting branches off a PVC lateral irrigation pipe sized according to the irrigation plans.
SCH. 80 PVC NIPPLE (OPTIONAL). SWING JOINT. SEE DETAIL. SCH. 40 PVC TEE OR ELBOW. PVC LATERAL IRRIGATION PIPE. (SEE IRRIGATION PLANS FOR PIPE SIZE AND TYPE). POP-UP ROTOR TO BE SET AT FINISH GRADE. (SEE IRRIGATION LEGEND FOR MAKE AND MODEL) FINISH GRADE POP-UP ROTOR TO BE SET AT FINISH GRADE. (SEE IRRIGATION LEGEND FOR MAKE AND MODEL) bj TV i a pn
