The control panel assembly features multiple input and output modules alongside power supply units, a CRA 31210 module, an NRP 0201 module, and an XBE module with terminal connections. Internal wiring links the modules within the panel enclosure located in the basement near MHF 1.
SCB BASEMENT: NEAR MHF 1 PLC 70 I/O DROP 7 I/O I/O I/O I/O CRA PS PS T XBE 31210 NRP 0201 I/O I/O I/O I/O PNL-71470 ASH SYSTEM CONTROL PANEL 1
