An interior wall partition meets a concrete fill over metal deck assembly perpendicularly with a compensation track at the partition head. Deck flutes are filled completely with mineral wool from both sides and sealed airtight with spray-applied sealant and continuous acoustic sealant on both sides. The wall cavity contains full-height acoustic insulation friction-fit between studs. A continuous plate is provided per detail 5 on sheet I-M02 at the top track.
ACOUS. INSUL CONCRETE FILL OVER METAL DECK, SSD FILL DECK FLUTES FULL FROM BOTH SIDES WITH MINERAL WOOL AND SEAL AIRTIGHT WITH SPRAY-APPLIED SEALANT ON BOTH SIDES OF THE WALL PARTITION AS SCHEDULED, FULL HEIGHT MINERAL WOOL ACOUSTIC FILL FRICTION FIT TO FILL ENTIRE CAVITY CONCRETE FILL OVER METAL DECK, SSD CONT. ACOUSTIC SEALANT EACH SIDE COMPENSATION TRACK ACOUS. INSUL W.O. PARTITION AS SCHEDULED CONT. PLATE SEE DETAIL 5 / I-M02 3" = 1'-0" 13 ACOUSTIC PARTITION PERPENDICULAR TO METAL DECK
