The pressure gauge mounts to a stainless steel snubber connected via a diaphragm seal when required. An isolation plug valve sits below the seal inline with the piping. A calibration connection branches off the assembly between the valve and the welded connection to the main pipe.
ENCLOSED IN NEMA 4X COVER. CONDUIT OUTLET CONNECTION 0 10 20 30 40 50 60 70 80 90 100 DIAPHRAGM SEAL (IF REQUIRED) S.S.SNUBBER PRESSURE GAUGE ISOLATION PLUG VALVE WELDED CONNECTION CALIBRATION CONNECTION
