A recessed light fixture integrates into a slotted wood ceiling assembly with equal alignment spacing. The adjoining wall partition features stud framing and seven-eighths-inch furring channels supporting gypsum board and an acoustic plaster finish. An LED strip light is housed within the pocket formed by the ceiling and partition junction. The wood ceiling construction aligns with reflected ceiling plan requirements.
EQ EQ ALIGN ALIGN LIGHT FIXTURE, SLD WOOD CEILING SEE RCP ACOUSTIC PLASTER ASSEMBLY, REF DETAIL PARTITION & FINISH AS SCHEDULED 4" 7/8" FURRING CHANNELS STUD FRAMING, AS NEC 4" 1 / I-M03 LED STRIP LIGHT, SLD GYP AS REC TO MEET ACOUSTIC REQs 3" = 1'-0" 7 TYP RECESSED FIXTURE @ WD CLG - SECTION
