Telecommunications · I-QDJ4G

SCB Control Room PLC Processor Cabinet Network Connections

Elements

Walls Millwork / Casework Connections / Plates

About this detail

This diagram details the single-mode fiber optic network connections and hardware layout for the SCB control room programmable logic controller processor cabinet PNL-74768 located on the existing south wall. The configuration incorporates PLC 70A and PLC 70B processors, BMEH584040 modules, NOC 0301 network modules, and power supplies linked to the PCS network. A shared MOXA IMC-21GA rack provides connections to the electrical device networks for PLC 70, PLC 71, and PLC 72. Specific connections route through A-side lines while referencing sheet I-00-607B for B-side electrical device network connections.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
