An air relief valve is installed at the high points in the drip zone on a schedule 80 polyvinyl chloride riser connected to a polyvinyl chloride schedule 40 tee on the main header pipe. The assembly sits inside a subterranean emitter box with its lid flush to the finish grade. The entire tee fitting rests on a minimum depth of three inches of three-quarter-inch washed gravel bed for drainage and support. A schedule 40 female adapter connects the valve to the riser pipe.
FINISH GRADE SUBTERRANEAN EMITTER BOX: RAIN BIRD SEB 7XB 12 " AIR RELIEF VALVE: RAIN BIRD ARV050 TO BE INSTALLED AT HIGH POINTS IN DRIP ZONE PVC SCH 40 FEMALE ADAPTER PVC SCH 80 RISER PVC HEADER PIPE PVC SCH 40 TEE 3" MINIMUM DEPTH OF 3/4" WASHED GRAVEL
