Multiple pipes or conduits pass through a scheduled partition wall outfitted with a metal sleeve provided by the trade of the penetrating item. The annular joint receives a one-half inch minimum to one-inch maximum fill of fire safing per manufacturer requirements to maintain required fire ratings. Acoustical sealant is applied to seal the joint without diminishing the fire safing effect. The gap around the metal sleeve is filled with drywall fire code compound, then taped and sanded to form a complete seal to the drywall.
ACOUS. INSUL W.O. PARTITION AS SCHEDULED FILL ALL AROUND METAL SLEEVE WITH DRYWALL FIRE CODE COMPOUND. TAPE AND SAND TO FORM A COMPLETE SEAL TO DRYWALL. PIPE OR CONDUIT MULTIPLE PIPES OR CONDUITS THRU DRYWALL OR PLASTER, MASONRY, OR CONCRETE. METAL SLEEVE PROVIDED BY TRADE OF PENETRATING ITEM PROVIDE ACOUSTICAL SEALANT AS REQUIRED PER PLANS. SEALANT SHALL NOT DIMINISH FIRE SAFING EFFECT FOR RATINGS REQUIRED. VERIFY WITH MFR. 1/2" MIN - 1" MAX FILL ANNULAR JOINT WITH FIRE SAFING PER MANUFACTURER'S REQUIREMENTS FOR FIRE RATINGS REQUIRED PER PLANS. FIRE SAFING SHALL BE COMPATIBLE WITH SURROUNDINGS AND PENETRATING MATERIALS. MINIMIZE
