A tree rootball irrigation assembly connects a polyvinyl chloride lateral line using schedule 40 polyvinyl chloride fittings routed entirely around the rootball without piercing it. A half-inch schedule 80 gray male adapter connects to a half-inch Salco ultraviolet-resistant polyvinyl chloride flexible hose. Nine-gauge tubing stakes secure the hose assembly adjacent to the rootball. The lateral line is positioned twelve inches below finish grade.
PVC LATERAL LINE ROUTED AROUND ROOTBALL (DO NOT GO THROUGH ROOTBALL) SCH. 4O PVC FITTINGS (TYPICAL) PVC LATERAL LINE FINISH GRADE 1/2" SCH. 80 MALE ADAPTER (GRAY) 9 GAGE TUBING STAKE 1/2" SALCO UV RESISTANT PVC FLEXIBLE HOSE (PVC AR-050) ROOTBALL BUBBLER TREE 12"
