A center feed inline drip irrigation system is configured for a planted mound or berm. The setup includes a remote control valve equipped with a filter and pressure regulator connected to PVC supply headers installed at a twelve-inch depth. Polyvinyl chloride exhaust headers connect to the dripline laterals, which feature inline drip emitters with spacing to be determined on center. Air and vacuum relief valves are plumbed to the tubing at each high point, alongside perimeter laterals positioned two inches from the edge. Zone flush valves and operation indicators complete the assembly to manage system flushing and operational status.
AV FV MANIFOLD CONNECTION (PVC TO ELL) PVC SUPPLY HEADER (12" DEPTH) MANIFOLD CONNECTION REMOTE CONTROL VALVE WITH FILTER AND PRESSURE REGULATOR DRIPLINE LATERAL AIR/VACUUM RELIEF LATERAL BLANK TUBING CENTERED ON MOUND OR BERM AIR/VACUUM RELIEF VALVE (PLUMBED TO TUBING AT EACH HIGH POINT) IN OPERATION INDICATOR PVC EXHAUST HEADER ZONE FLUSH VALVE PLUMBED TO PVC (TYP) PERIMETER LATERAL 2" FROM EDGE INLINE DRIP EMITTER (O.C. SPACING TBD) FV
