A Schluter Schiene-AE metal edge profile separates porcelain or quarry tile set in a thin set mortar bed from resilient flooring such as LVT or sheet vinyl. The metal profile profile is completely filled with thin set mortar for edge support. The flooring transition occurs at the center of the door leaf unless noted otherwise. Resilient flooring is floated or leveled as necessary to avoid any abrupt change in height at the transition.
RESILIENT FLOORING (RF, LVT, SVF) PORCELAIN TILE (TPF), QUARRY TILE (QT) SCHLUTER SCHIENE-AE THIN SET MORTAR BED COMPLETELY FILL PROFILE WITH THIN SET MORTAR NOTE: FLOORING TRANSITION TO OCCUR AT CENTER OF DOOR LEAF, U.N.O. NOTE: FLOAT RESILIENT FLOORING OR USE LEVELER STRIP AS NECESSARY TO AVOID ABRUPT CHANGE IN HEIGHT AT TRANSITION C:\Revit Local Files\184048.00 EH Chula Vista-A19 Central_gbeasleyG68AC.rvt 3" = 1'-0" ID1.20 D16 SERVERY WALL ISO AT TILE TO RUBBER BASE TRASITION
