Electrical Control Panel Network Architecture Diagram

Materials

Elements

Floors / Slabs Millwork / Casework Connections / Plates

About this detail

Network connections and device layouts for programmable logic controllers, variable frequency drives, and operator interface terminals span multiple plant levels. Single-mode fiber optic cables and CAT-6 network cables link the control panels to motor control centers and remote I/O drops. DIN-rail mounted MOXA IMC-21GA modules facilitate network communication between the centrifuge control panels and associated equipment. Panel designations, including PLC-CFG2 and PLC-CFG4, map out the device architecture for cake pump and centrifuge control panels on the first, second, and third floors. General notes specify wiring conventions, patch panel requirements for copper and fiber cables, and device allocations provided by equipment suppliers.

NOTES: 1. CONNECTIONS TO POWER DISTRIBUTION B-SIDE SMART MCC RELAYS FOR MCC61C2, MCC72U2, MCC73T2, MCC73T4, MCC73S2, AND MCC73S4 ARE NUMBERED. REFER TO I-00-609 FOR TABLES WITH CORRESPONDING DEVICES. 2. CONNECTIONS TO POWER DISTRIBUTION B-SIDE VFD'S POWERED BY MCC61C2, MCC72U2, MCC73T2, MCC73T4, MCC72S2, AND MCC73S4 ARE NUMBERED. REFER TO I-00-609 FOR TABLES WITH CORRESPONDING VFD'S. 3. CONNECTIONS TO CENTRIFUGE MAIN DRIVE AND BACK DRIVE VFD'S LOCATED IN SCB 2ND FLOOR ELECTRICAL ROOM. TYPICAL FOR ALL FOUR CENTRIFUGES. 4. SCB PLC 70 IS SHOWN ON BOTH I-00-607A AND I-00-607B TO PRESENT THE A-SIDE AND B-SIDE ELECTRICAL DEVICE NETWORKS SEPARATELY. 5. ALL COPPER AND FIBER COMMUNICATION CABLES BETWEEN CABINETS SHALL LAND ON PATCH PANELS. PATCH PANELS NOT SHOWN FOR CLARITY. 6. REDUNDANT PLC 70 PROCESSORS, POWER SUPPLIES, AND BACKPLANES ARE EXISTING. 7. MCC'S AND THE SWITCHES IN THEM WILL BE PROVIDED BY THE MCC SUPPLIER. LEGEND SINGLE-MODE FIBER OPTIC CABLE CAT-6 NETWORK CABLE SCB ELECTRICAL ROOM PLC-CFG2 I/O DROP 1 OIT SCB 1ST FLOOR - CAKE PUMP 2 HPU CONTROL PANEL PLC-CFG2 BMEP584040 NOC 0301 I/O I/O I/O I/O CRA T XBE 31210 I/O I/O I/O I/O OIT SCB 3RD FLOOR- CENTRIFUGE 2 CONTROL PANEL PLC-CFG2 I/O DROP 2 PLC-CFG2 I/O DROP 3 SCB 2ND FLOOR-CAKE PUMP 2 CONTROL PANEL I/O I/O I/O I/O CRA T XBE 31210 I/O I/O I/O I/O PLC-CFG4 I/O DROP 1 SCB 1ST FLOOR - CAKE PUMP 4 HPU CONTROL PANEL PLC-CFG4 NOC 0301 I/O I/O I/O I/O CRA T XBE 31210 I/O I/O I/O I/O OIT SCB 3RD FLOOR- CENTRIFUGE 4 CONTROL PANEL PLC-CFG4 I/O DROP 2 PLC-CFG4 I/O DROP 3 SCB 2ND FLOOR-CAKE PUMP 4 CONTROL PANEL I/O I/O I/O I/O CRA T XBE 31210 I/O I/O I/O I/O NOC 0301 I/O I/O I/O I/O I/O NOTE 3 OIT I/O I/O I/O I/O I/O I/O T XBE I/O T XBE I/O I/O BMEP584040 I/O I/O I/O I/O NOTE 3 NOC 0301 PNL-74028 PNL-73186 PNL-72421 PNL-74049 PNL-73195 PNL-72423 VFD-74022 VFD-74023 VFD-74047 VFD-74048 PS PS PS PS PS PS PS PS PS PS PS PS PNL-73450 SCB ELECTRICAL ROOM NETWORK CABINET IMC- 21GA DIN-RAIL MOUNTED MOXA IMC-21GA MODULE IMC- 21GA DIN-RAIL MOUNTED MOXA IMC-21GA MODULE PROVIDED BY CAKE PUMP SUPPLIER PROVIDED BY CAKE PUMP SUPPLIER PROVIDED BY CAKE PUMP SUPPLIER PROVIDED BY CAKE PUMP SUPPLIER PROVIDED BY CENTRIFUGE SUPPLIER PROVIDED BY CENTRIFUGE SUPPLIER
