A pop-up rotor irrigation head is set flush with the finish grade, connected to an optional Schedule 80 PVC nipple and a swing joint. The assembly ties into a Schedule 40 PVC tee or elbow, which connects to the PVC lateral irrigation pipe sized per the irrigation plans. The rotor make and model are specified in the irrigation legend.
SCH. 80 PVC NIPPLE (OPTIONAL). SWING JOINT. SEE DETAIL. SCH. 40 PVC TEE OR ELBOW. PVC LATERAL IRRIGATION PIPE. (SEE IRRIGATION PLANS FOR PIPE SIZE AND TYPE). POP-UP ROTOR TO BE SET AT FINISH GRADE. (SEE IRRIGATION LEGEND FOR MAKE AND MODEL) FINISH GRADE POP-UP ROTOR TO BE SET AT FINISH GRADE. (SEE IRRIGATION LEGEND FOR MAKE AND MODEL)
