A watertight two-wire splice connection links to a lightning arrestor and a 5/8-inch by 8-foot copper-clad ground rod. The inset details show the internal wire strip dimensions with a 4-inch stripped length and a 1-inch terminal margin. The splice features a water-tight configuration for electrical grounding systems.
LIGHTNING ARRESTOR 5/8" X 8' COPPER CLAD GROUND ROD TW-SPLICE WATER-TIGHT CONNECTION STRIP WIRE 4" 1"
