I-FQAYW — Damper Actuator

Mechanical · I-FQAYW

Damper Actuator

About this detail

A damper actuator control scheme features open and closed limit switches alongside position feedback points. Signal designations include ZT, ZI, ZSC, ZSO, ZLC, ZL0, LR, and OSC for hearth control coordination. The configuration links directly to standard modulating damper actuator input and output points for hearth 5.

ZT . ZI . DAMPER ACTUATOR ZSC . ZSO . . ZLC . ZLO HS . LR HS . OSC SEE TYPICAL MODULATING DAMPER ACTUATOR I/O FOR HEARTH 5

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
