Mechanical · I-EMZZD

Typical Open/Close Valve Actuator I/O

About this detail

Signal mapping for remote input, fully closed, fully opened, failure alarms, close commands, open commands, level monitoring, and high-level alarms for an open and close valve actuator.

LI 0061 LEVEL LI 0061 LEVEL YI 0111 REMOTE IN YI 0111 REMOTE IN ZIO 0111 OPENED FULLY ZIO 0111 OPENED FULLY ZIC 0111 CLOSED FULLY ZIC 0111 CLOSED FULLY ZCC 0111 CMD CLOSE ZCC 0111 CMD CLOSE ZCO 0111 CMD OPEN ZCO 0111 CMD OPEN YA 0111 FAIL YA 0111 FAIL TYPICAL OPEN/CLOSE VALVE ACTUATOR I/O LAH 0061 LEVEL HIGH LAH 0061 LEVEL HIGH

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
