Programmable logic controller assembly designated as PLC 71 I/O Drop 4 for Furnace 1 panel PNL-72673. The enclosure contains dual power supply modules labeled PS, communication adapters including CRA 31210 and NRP 0201 modules with routed cabling, multiple standard input/output modules, and an XBE module.
PLC 71 I/O DROP 4 SCB 1ST FLOOR: NEAR DRY SCRUBBER 1 PNL-72673 FURNACE 1 PLC I/O DROP 4 PANEL I/O I/O I/O I/O CRA PS PS T XBE 31210 NRP 0201 I/O I/O I/O I/O
