Electrical · I-CW2TE

Polymer Feed Pump VFD Control Wiring Diagram

About this detail

Control diagram showing the Ethernet communication link and discrete I/O signals between PLC-70 and panel PNL-73416 housing variable frequency drive VFD-73412 for polymer feed pump 2. Signals include start command, stop command, running status, remote input, ready state, VFD failure, speed command, and speed feedback. Hand-off-auto switches and speed control indicators interface with the 480-volt motor controller.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
