An instrumentation control diagram for automatic backwash strainer 2 displays status points including auto in YI 1517, running YIR 1517, fail YA 1517, differential pressure PDH 1517, and high differential pressure PDAHH 1517.
PDAHH 1517 PRESS DIFF YA 1517 FAIL YIR 1517 RUNNING YI 1517 AUTO IN AUTOMATIC BACKWASH STRAINER 2 PDH 1517 PRESS DIFF
