A bench top with a mitered and eased edge featuring a one-and-a-half-inch nosing is scribed to the wall with a clear silicone sealant bead. The assembly is supported by Rakks EH-1818FM counter support brackets spaced at a maximum of thirty-two inches on center and a one-inch diameter Mockett custom round leg. A base is provided per the color and material legend.
BASE PER COLOR AND MATERIAL LEGEND RAKKS EH-1818FM COUNTER SUPPORT BRACKET AT 32" O.C. MAX, WHITE OR EQUAL SUPPORT BRACKET 24" MAX 20" MIN MITERED AND EASED EDGE WITH 1-1/2" NOSING SS PER INTERIOR ELEVATIONS, SCRIBE TO WALL CLEAR SILICONE SEALANT MOCKETT, CUSTOM ROUND LEG, 1" DIA.
