I-B74NC — Schluter Rondec Porcelain Tile Trim

Interiors · I-B74NC

Schluter Rondec Porcelain Tile Trim

Materials

About this detail

Schluter Rondec satin nickel trim profile RO10OAT terminates and protects porcelain tile edges at ninety degree and angled wall corners. The trim profile integrates with the specified tile height coordinated per the finish material legend.

SCHLUTER "RONDEC" TRIM PROFILE RO1OOAT, SATIN NICKEL REFERENCE FINISH MATERIAL LEGEND FOR FINISH NOTE: COORDINATE TRIM PROFILE WITH SPECIFIED TILE HEIGHT 90 DEGREE CORNER ANGLED CORNER

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
